About abVisualRTL
State Diagrams to HDL
abVisualRTL turns state diagrams into hardware. You place states on a zoomable canvas, draw transitions between them, and attach conditions, priorities and Moore or Mealy output actions — then the tool generates synthesizable RTL you can drop straight into a design.
